ImmersionRC Vortex 250 Pro 2204 2300kV V Spec Motor

ImmersionRC Vortex 250 Pro 2204 2300kV V Spec Motor

These replacement ImmersionRC Vortex motors are the motors supplied on the Immersion RC Vortex 250 FPV Mini Racing system. The Vortex 250 motor is supplied with the M5 CW propeller nyloc nut.

Motor Spec:



• kV(RPM/V): 2300kV

• Lipo Cells: 3 – 4S

• Max Current: 126.5W

• Max Amps: 11.5A

• No Load Current: 0.6A/10V

• Internal Resistance: 0.125 ohm

• Number of Poles: 12N/14P

• Dimensions(Dia.xL): 22 x 4mm

• Motor Shaft: 3mm

• Prop Shaft: 5mm

• Weight: 24g

• Bolt Hole Spacing: 12 x 16mm,16 x19mm

• Lamination Thickness: 0.2mm

• Magnets:N45SH

• Balancing Spec: 0.005g or better
